Supermarket Shelves Plastic Label Extrusion Making Machine Plastic Price Tag Strip Production Line
제품 세부정보
| 파이프 직경: | 75-250 | 압출기의 힘: | 55kW |
|---|---|---|---|
| 색상: | 사용자 정의 | 파이프 움 버: | 이중 파이프 |
| 원료: | PVC 파우더 및 첨가제 | 애플리케이션: | 급수 파이프 |
| 전압: | 380V 50Hz 또는 사용자 정의 | 자동 등급: | 완전한 원자력 |
| 나사 디자인: | 트윈 스크류와 배럴 | 애프터 판매 서비스 제공: | 해외 서비스 기계, 현장 설치, 시운전 및 교육, 온라인 지원, 비디오 기술 지원 엔지니어 |
| 보증: | 18 개월 | 인버터: | 씨줄 |
| 색상: | 사용자 정의 가능 | 원료: | PVC 파우더 |
| 모터: | 지멘스 브랜드 | 접촉기: | 지멘스 또는 슈나이더 |
| 나사와 배럴: | 원뿔형 트윈 스크류 압출기 | 나사 직경: | 65/132 |
| 파이프 응용 프로그램: | 상수도 | 패키지: | 영화와 상자 |
| 지불: | T/T, L/C, Western Union | 배달 시간: | 60 일 |
| 강조하다 |
Plastic Price Tag Strip Production Line,Supermarket Shelves Label Extrusion Line |
||
제품 설명
Supermarket Shelves Plastic Label Extrusion Making Machine Plastic Price Tag Strip Production Line
Short description
The PVC profile production line is widely used for producing various PVC profiles, such as PVC window&door profile, PVC ceiling panel, PVC trunking. With drawing sections of the PVC profile, tailed solutions and mould will be made.
Processing Process
The process flow of this line is PVC powder + additive - mixing-material feeder-twin screw extruder- mould and calibrator-vacuum forming table-haul-off machine-cutting machine-discharge rack.
This PVC profile extrusion line adopts conical twin screw extruder, which is suitable for both PVC powder and PVC granules. It has degassing system to ensure the excellent material plasticization. The high speed mould is available, and it can largely increase the productivity.
Application
Suitable for supermarkets,convenience stores,chain stores,wholesale markets for fruit and food placement labels.The products have many varieties,bright transparency not easy to break,durable and other characteristics.
Specifications
|
Model
|
LB180 | LB240 | LB300 | LB600 |
|
Max width of products(mm)
|
180 | 240 | 300 | 600 |
|
Screw Model
|
SJ55/110
|
SJ65/132
|
SJ65/132
|
SJ80/156
|
|
Motor power
|
22KW
|
37KW
|
37KW |
55KW
|
|
Cooling Water(m3/h)
|
5 | 7 | 7 | 10 |
|
Compressor(m3/h)
|
0.2 | 0.3 | 0.3 | 0.4 |
|
Total length(m)
|
18m | 22m | 22m | 25m |
